1360

  • Paving Widths from 4ft to 8ft
  • Designed for Maximum Versability to Complete Any Job
  • Tier 4 Final 66hp Diesel Engine
  • Heaviest Screed in Class to Ensure Best Mat Quality
  • Designed for Easy Access Serviceability
  • Standard Sonic Sensor Auger Control
DOCUMENTATION
Dimensions:

Length ft: 14ft 4in (4.36m)
Width ft (cm) :283 cm ( hopper opened)
Height: 7ft 3 in (1.9m)
Weight:13,000 lb (5897 kg)
Screed Weight: 2000 lb (907 kg)
Truck Clearance: 22 in (56 cm)
Track Pad Width: 8 in (20 cm)
Track Length: 37 in (94 cm)

Capacities:

Hopper Capacity: 5.5 Tons
Fuel Tank: 22 gal (83L)
Hydraulic tank Gal (L) *
Washdown Tank Gal (L) *

Performance:

Paving Widths ft (m): 10.2 ft
Paving Depth in (cm) :7.9 /-5.9 in
Heating Source: Electric Heat
Augers: 12 in diameter
Paving Speed fpm (mpm): 90 fpm
Travel Speed fpm (mpm) :180fpm

Engine:

Manufacturer: Deutz
Displacement Liters:
Tier 4 Final
HP: 66hp
