3500

  • 3000Lb operating weight
  • Largest in Class Diameter for better compaction
  • Large 50gal water tank capacity
  • Front Vibratory Drum
  • Best in Class Operator Comfort
  • Available in Diesel or Gasoline
DOCUMENTATION
BID SPEC
Dimensions

Length in (cm) 83” (210cm)
Height in (cm) 63” (160cm)
Width in (cm) 38” (96cm)
Max Weight Lbs (kg) 3085lbs (1400kg)

Drums

Front
Width in (mm) 35.4” (900mm)
Diameter in (mm) 23” (584mm)

Rear
Width in (mm) 35.4” (900mm)
Diameter in (mm) 23” (584mm)

Engine

Manufacturer: Honda
HP: 19

Optional Equipment

Engine
Manufacturer: Kubota
HP: 20
