MT300 / 600

  • 300 or 600 Gallon Tank Capacity
  • Hydraulic-Driven, Reversible Asphalt Pump
  • Dished and Flanged Heads for Superior Leak Protection
  • Wash Down Solvent Tank
  • 20″ Manhole
  • 5′ Cold-Handle Hand Sprayer with 40′ Hose
  • Electronic Break-Away Braking System
  • Triple-Pass, Single Flue with Choice of Heating:
    • Thermostat-Controlled Diesel Burner
    • Propane
  • 8′ Non-Recirculating Spray Bar with In-Cab Control*
DOCUMENTATION
Dimensions

Overall Length: 169″, 1430 cm
Overall Width: 96.5″, 1245 cm
Loading Height: 62″, 158 cm | 70″, 178 cm
Tires: 225/75R15
Brakes: Electric, Single Axle

Performance Data

Asphalt Pump 8 GPM 1 30 LPM, Reversible Hydraulic Driven
Heating, Type Propane, Twin Burners
Heating Flue Diameter: 8″ / 20cm
Single Flue Tube with Triple Tank Pass
Hand Spray Wand Single Nozzle
Hand Spray Hose 40 Feet/ 12 Meters
Hand Spray Hose Reel Manual Wind

Engine

Fuel Type Gasoline
Power 9.5 HP (SAE/1394) | 7Kw
Type and Cooling 1 Cylinder – Electric Start, Air Cooled

Fluid Capacities

Solvent Tank 5 Gal. 1 19 L
Hydraulic Tank 5 Gal. 19 L
Diesel Tank, (if equipped) 5 Gal, 1 19 L
